Hours Diagnostics
Hours Diagnostics
Controller (hr)
The number of Hours the WMA-5 has been Powered
IRGA (hr)
The number of Hours the CO2 IRGA has been Powered
Back Button
Returns the display back to the Diagnostic Menu.
Voltage Diagnostics
Voltage Diagnostics
External (V)
The measured voltage powering the WMA-5
Flow Sen (V)
The voltage measured from the Flow sensor
Aux (V)
The voltage applied to the Aux input (range 0 - 1.000)
O2 Sen (V)
The voltage measured from the O2 sensor
Back Button
Returns the display back to the Diagnostic Menu.
