Ether232Plus User Guide Appendix B: Troubleshooting and Support
02-CML000027 Precidia Technologies Inc. B-5
Indicator Lamps (LEDs)
ON lamp
The ON lamp indicates power is available to the Ether232Plus.
ETHERNET – LINK lamp
Illuminates when the Ethernet port has a 10BaseT Ethernet network connection.
Table B.2: ON Lamp Troubleshooting
Lamp Status Standard Troubleshooting Procedure
On OK - unit
has power
None
Off Unit has no
power
• Check connection of the power adapter into the
Ether232Plus
• Check to confirm the opposite end (with the black
transformer) is plugged into a power outlet
• Check the power outlet by plugging in a "known
operational" power plug
• Replace the power adapter with one approved by
Precidia
Table B.3: LINK Lamp Troubleshooting
Lamp Status Standard Troubleshooting Procedure
On OK - Ethernet
connection in
place
None
N
OTE
: This light may be on if the Ether232Plus is
not configured.
Off No Ethernet
connection
• Ensure the Ethernet cable is properly plugged
into the Ether232Plus.
• Ensure the Ethernet cable's opposite end is prop-
erly plugged into your LAN hub.
N
OTE
: The hub also has Link lamps that will
provide further troubleshooting information.
