Appendix B: Troubleshooting and Support Ether232Plus User Guide
B-6 Precidia Technologies Inc. 02-CML000027
ETHERNET – COLLISION lamp
Illuminates when more than one device is trying to use the Ethernet at the same time.
The IP protocol automatically attempts to rectify the situation and data is rarely lost.
ETHERNET – TRANSMIT lamp
Illuminates when the Ether232Plus is sending or receiving data via the Ethernet port.
Normally you will see very short data bursts.
Table B.4: COLLISION Lamp Troubleshooting
Lamp Status Standard Troubleshooting Procedure
On Collision
between data
streams has
occurred
• Ensure the Ethernet cable is properly plugged
into the Ether232Plus.
• Check that the Ethernet cable's opposite end is
properly plugged into your LAN hub.
N
OTE
: The hub also has Link lamps that will
provide further troubleshooting information.
Off OK
None
Table B.5: TRANSMIT Lamp Troubleshooting
Lamp Status Standard Troubleshooting Procedure
Flashing OK - data is
being trans-
mitted
None
Off No data is
being trans-
mitted
Ensure the Ethernet cable between the
Ether232Plus and the Ethernet device is properly
connected
