Model PD6000 Analog Input Process Meter Instruction Manual
26
Display Functions & Messages
The meter displays various functions and messages during setup, pro-
gramming, and operation. The following table shows the main menu
functions and messages in the order they appear in the menu.
Display Parameter Action/Setting Description
reset
Reset
Press Enter to access the Reset menu
Rst Hi
Reset high
Press Enter to reset max display
Rst Lo
Reset low
Press Enter to reset min display
Rst HL
Reset
high & low
Press Enter to reset max & min displays
Contrl
Control
Enter Control menu
Auto
Automatic
Press Enter to set meter for automatic
operation
mAn
Manual
Press Enter to manually control relays or
analog output operation
setup
Setup
Enter Setup menu
input
Input
Enter Input selection menu
mA
4-20 mA
Set meter for 4-20 mA input
volt
0-10 VDC
Set meter for ±10 VDC input
Dec pt
Decimal point
Set decimal point
dsplay
Display
Enter the Display menu
big
Big display
Press Enter to assign the Main display
parameter (default: PV)
Little
Little display
Press Enter to assign the small display
parameter (default: engineering units)
d-Inty
Display
intensity
Set display intensity level from 1 to 8
RELaY
Relay
Enter the Relay menu
RLY 1
Relay 1
Relay 1 setup
Act 1
Action 1
Set relay 1 action
Auto
Automatic
Set relay for automatic reset
A-man
Auto-manual
Set relay for automatic & manual reset any
time
