Model PD6000 Analog Input Process Meter Instruction Manual
78
Factory Defaults & User Settings
The following table shows the factory setting for most of the programm-
able parameters on the meter. Next to the factory setting, the user may
record the new setting for the particular application.
Model: ______________ S/N: _______________ Date: _________
Paramete
r
Display Default Setting User Setting
Input type
input
4-20 mA
Filter
filter
10
Bypass
bypass
0.2
Function
Functn
Linear
Number of points
No Pts
2
Programming
prog
Scale
Input 1
InP 1
4.000 mA
Display 1
Dis 1
4.000
Input 2
InP 2
20.000 mA
Display 2
Dis 2
20.000
Decimal point
dd.ddd
3 places
Cutoff value
CutofF
0.000 (disabled)
Display assignment
Dsplay
Big display (Main)
big
PV: Process variable
Little display (Small)
Little
Eng units: mA
Display intensity
d-Inty
6
Relay 1 action
Act 1
Automatic
Relay 1 set point
Set 1
1.000
Relay 1 reset point
RSt 1
0.500
Relay 2 action
Act 2
Automatic
Relay 2 set point
Set 2
2.000
Relay 2 reset point
RSt 2
1.500
Relay 3 action
Act 3
Automatic
Relay 3 set point
Set 3
3.000
Relay 3 reset point
RSt 3
2.500
