Model PD6000 Analog Input Process Meter Instruction Manual
3
INTRODUCTION
The PD6000 is a multipurpose, easy to use digital process meter ideal for level,
flow rate, temperature, or pressure transmitter applications. It accepts current
and voltage signals (e.g. 4-20 mA, 0-10 V). Three of the front panel buttons can
be custom-programmed for specific operation.
The basic model includes an isolated 24 VDC transmitter power supply that can
be used to power the input transmitter or other devices. An additional isolated
24 VDC power supply is included with the 4-20 mA output option.
A fully loaded PD6000 meter has the following: four SPDT relays, 4-20 mA output,
and two 24 VDC power supplies. The PD6000 capabilities may be enhanced by
adding the following external expansion modules: four SPST relays –creating an
eight-relay process meter–, two digital I/O modules with four inputs and four outputs
each, and RS-232 or RS-485 communication adapters.
The eight relays can be used for alarm indication or process control applications,
such as pump alternation control. The 4-20 mA isolated output, serial communica-
tions, and digital I/O options make the PD6000 an excellent addition to any system.
ORDERING INFORMATION
85-265 VAC
Model
12
24
DC
Model
Options Installed
PD6000-6R0 PD6000-7R0 No options
PD6000-6R2 PD6000-7R2 2 relays (PD1102*)
PD6000-6R3 PD6000-7R3 4-20 mA output (PD1103*)
PD6000-6R4 PD6000-7R4 4 relays (PD1104*)
PD6000-6R5 PD6000-7R5 2 relays & 4-20 mA output (PD1105*)
PD6000-6R7 PD6000-7R7 4 relays & 4-20 mA output (PD1107*)
*Model number for replacement option card.
Accessories
Model Description
PDA1002 DIN rail mounting kit for two expansion modules
PDA1004 4 SPST (Form A) relays
PDA1044 4 digital inputs & 4 digital outputs (2 may be connected)
PDA1200 Meter copy cable
PDA1232 RS-232 serial adapter
PDA1485 RS-422/485 serial adapter
PDA7485-I RS-232 to RS-422/485 isolated converter
PDA7485-N RS-232 to RS-422/485 non-isolated converter
PDA8232-N USB to RS-232 non-isolated converter
PDA8485-I USB to RS-422/485 isolated converter
PDA8485-N USB to RS-422/485 non-isolated converter
PDX6901
Suppressor (snubber): 0.01 µF/470 Ω, 250 VAC
