Model PD6000 Analog Input Process Meter Instruction Manual
Scaling the 4-20 mA Analog Output (Aout)
The 4-20 mA analog output can be scaled to provide a 4-20 mA signal
for any display range selected.
No equipment is needed to scale the analog output; simply program the
display values to the corresponding mA output signal.
The
Analog Output menu is used to program the 4-20 mA output based
on display values.
Aout
setup
dis 1
Aout
004.000
dis 1
dis 2
Aout
020.000
dis 2
Out 1
Aout
04.000
Out 1
Out 2
Aout
20.000
Out 2
For instructions on how to program
numeric values see
Setting Numer-
ic Values
, page 30.
57
