© Precor Incorporated, Unauthorized Reproduction and Distribution Prohibited by Law
Figure 62: Gas Shock
Caution: It is recommended to have assistance available for the
following step(s).
14 With assistance, lift the front of the Incline platform until the
Incline tube mounting holes align with the Incline platform mounting
holes.
15 Thread the Incline motor mounting pin through the Incline tube and
Incline platform and attach the hitch pin.
16 Replace the wave washer and flat belt pulley, secure the flat belt
pulley with the snap ring.
17 Lift the stairarm and thread the inside flat belts through the flat
belt pulleys.
18 Replace the covers per procedure, Cover Replacement (on page 152).
19 Operate the incline through its entire range to ensure proper
operation.
