24. Attach Lat Bar Holders
A. Attach the Lat Bar Holders to the Top Beam using
two 3¼-inch bolts
four washers
two locknuts
B. Wrench tighten.
Step 24. Attach Lat Bar Holders
2 - 3¼" bolts
4 - washers
2 - locknuts
A
Top Beam
Lat Bar Holders
