1.Introduction
Keyboard &
Pointing Device
Winkey Keyboard Built-In TouchPad
PCMCIA One Type II PCMCIA 3.3V/5V Socket Supporting CardBus
Interface &
Communication
Two USB 2.0 Ports
One Infrared Transceiver (IrDA 1.1 FIR/SIR/ASKIR)
Infrared Transfer 1cm ~ 1M Operating
Distance
115.2K bps SIR
4M bps FIR
One VGA Monitor (VGA) Port
One Headphone Jack
One Microphone Jack
One DC-In Jack
One RJ-11 Jack (Modem)
One RJ-45 Jack (Local Area Network)
10/100 BASE-T Compatible
Video Camera Module (Factory Option)
Integrated V.90/56K MDC Modem (V.92 Compliant)
MDC & Bluetooth Combo Module (Factory Option)
Intel/PRO Wireless 2100 Mini PCI I/F 802.11b Wireless
LAN Module (Optional)
OR
Intel/PRO Wireless 2200BG Mini PCI I/F 802.11b/g
Wireless LAN Module (Optional)
Indicators LED Indicators (Wireless On/Off, HDD Activity, Suspend/Power On/AC-In, Battery Charging/Battery Full, Num Lock,
Caps Lock, Scroll Lock)
Power
Management
Supports ACPI v1.0b/2.0
Supports Hibernate/Standby Modes
Supports Battery Low Sleep
Supports Resume From Modem Ring
Power Full Range AC Adapter - AC-In 100~240V, 50~60Hz, DC Output 65W
Standard - Easy Changeable, 4 Cell, 4800mAH, 35.5 Whrs, Main Battery Smart Li-Ion
Optional - Easy Changeable, 8 Cell, 4400mAH / 4800mAH, 65.2 / 71 Whrs, Main Battery Smart Li-Ion
Environmental
Spec
Temperature
Operating: 5
°C ~ 35°C
Non-Operating: -20°C ~ 60°C
Relative Humidity
Operating: 20% ~ 80%
Non-Operating: 10% ~ 90%
Physical
Dimensions &
Weight
295mm (w) * 235mm (d) * 26-33mm (h) 1.7kg without Battery
Feature Specification
TECHNICAL SERVICE MANUALPrestigio Visconte 125W
3
