Prestigio Visconte - Removing the LCD Panel

2.Disassembly
Removing the LCD Panel
1. Turn off the computer and remove the battery (page 2 - 7), HDD (page 2 - 8), RAM (page 2 - 10), optical device
(page 2 - 11), WLAN module (page 2 - 12), processor (page 2 - 13), keyboard & shielding plate (page 2 - 15), sep-
arate the top & bottom cases (page 2 - 17), disconnect any Bluetooth antenna cable (page 2 - 19), remove the
LCD front panel module (page 2 - 21) and remove the inverter (page 2 - 22).
2. Remove screws - and the hinge covers .
3. Disconnect the cable at point if you need to remove the PC Camera module .
1
11
12
Figure 2 - 17
Removing the LCD
Panel
Remove the screws.and
hinge covers

12. Hinge Covers
14. PC Camera
•11 Screws
1
2
3
4
567
8
10
11
12
12
13
14
9
13
14
TECHNICAL SERVICE MANUALPrestigio Visconte 125W
