2.Disassembly
4. Carefully lift the LCD forward and the remove the speakers and hinges .
5. If you need to remove individual cables (e.g. the speaker cables), or the LCD Panel, then the cables will need to be
separated from the tape .
1 2
3
Figure 2 - 18
Removing the LCD
Panel
Remove the speak-
ers.and hinges (sepa-
rate the cables from the
tape to remove the LCD
etc.).

1. Speakers
2. Hinges
3
1 12 2
