2.Disassembly
Disassembly Steps
The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM
THE DISASSEMBLY STEPS IN THE ORDER INDICATED.
To remove the Battery:
1. Remove the battery page 2 - 7
To remove the HDD:
1. Remove the battery page 2 - 7
2. Remove the HDD page 2 - 8
To remove the System Memory:
1. Remove the battery page 2 - 7
2. Remove the system memory page 2 - 10
To remove the Optical Device:
1. Remove the battery page 2 - 7
2. Remove the optical device page 2 - 11
To remove the Wireless LAN Module:
1. Remove the battery page 2 - 7
2. Remove the WLAN module page 2 - 12
To remove the Processor:
1. Remove the battery page 2 - 7
2. Remove the processor page 2 - 13
To remove the PC Camera:
1. Remove the battery page 2 - 7
2. Remove the PC Camera page 2 - 15
To remove the Keyboard & Shielding Plate:
1. Remove the battery page 2 - 7
2. Remove the keyboard & shielding plate page 2 - 16
To separate the Top & Bottom Cases:
1. Remove the battery page 2 - 7
2. Remove the HDD page 2 - 8
3. Remove the system memory page 2 - 10
4. Remove the optical device page 2 - 11
5. Remove the WLAN module page 2 - 12
6. Remove the processor page 2 - 13
7. Remove the keyboard & shielding plate page 2 - 15
8. Separate the top & bottom cases page 2 - 17
TECHNICAL SERVICE MANUAL Prestigio Visconte 125W
