2.Disassembly
To remove the Modem/Bluetooth Modem:
1. Remove the battery page 2 - 7
2. Remove the HDD page 2 - 8
3. Remove the system memory page 2 - 10
4. Remove the optical device page 2 - 11
5. Remove the WLAN module page 2 - 12
6. Remove the processor page 2 - 13
7. Remove the keyboard & shielding plate page 2 - 15
8. Separate the top & bottom cases page 2 - 17
9. Remove the modem/Bluetooth modem page 2 - 19
To remove the TouchPad:
1. Remove the battery page 2 - 7
2. Remove the HDD page 2 - 8
3. Remove the system memory page 2 - 10
4. Remove the optical device page 2 - 11
5. Remove the WLAN module page 2 - 12
6. Remove the processor page 2 - 13
7. Remove the keyboard & shielding plate page 2 - 15
8. Separate the top & bottom cases page 2 - 17
9. Remove the modem/Bluetooth modem page 2 - 19
10. Remove the TouchPad page 2 - 20
To remove the LCD Front Panel Module:
1. Remove the battery page 2 - 7
2. Remove the HDD page 2 - 8
3. Remove the system memory page 2 - 10
4. Remove the optical device page 2 - 11
5. Remove the WLAN module page 2 - 12
6. Remove the processor page 2 - 13
7. Remove the keyboard & shielding plate page 2 - 15
8. Separate the top & bottom cases page 2 - 17
9. Remove the modem/Bluetooth modem page 2 - 19
10. Remove the LCD front panel module page 2 - 21
To remove the Inverter:
1. Remove the battery page 2 - 7
2. Remove the HDD page 2 - 8
3. Remove the system memory page 2 - 10
4. Remove the optical device page 2 - 11
5. Remove the WLAN module page 2 - 12
6. Remove the processor page 2 - 13
7. Remove the keyboard & shielding plate page 2 - 15
8. Separate the top & bottom cases page 2 - 17
9. Remove the modem/Bluetooth modem page 2 - 19
10. Remove the LCD front panel module page 2 - 21
11. Remove the inverter page 2 - 22
