Section 2 Introduction
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
How Your Dryer Works
The dryer uses heated air to dry loads of laundry. When the motor is started, the exhaust fan pulls room
temperature air in through louvers at the rear of the dryer and over the heat source (burner flame for gas
and heating element for electric). The heated air moves through the heater duct and into the cylinder,
where it circulates through the wet load. The air then passes through the lint filter, air duct, and exhaust
fan, where it is vented to the outdoors.
D390SE3A
LINT
FILTER
CYLINDER
EXHAUST
FAN
HEATER
DUCT
