To reduce the risk of electric shock, fire, explosion, serious injury or death:
• Disconnect electric power to the dryer(s) before servicing.
• Close gas shut-off valve to gas dryer(s) before servicing.
• Never start the dryer(s) with any guards/panels removed.
• Whenever ground wires are removed during servicing, these ground wires must be
reconnected to ensure that the dryer is properly grounded.
W001R1
WARNING
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Section 7
Internal Wiring of Dryer Motor Switch
Figure 66
R
R
S
26 43 5 1
MAIN
START
ORANGE
CUSTOMER CIRCUIT
OVERLOAD
PROTECTOR
BROWN
BLACK
YELLOW
PUSH TO
START
LINE
SWITCH SHOWN IN START POSITION
R.S.P.C.
26 4 3 5 1
G
D329S
G
To Next Page
