Section 5 Service Procedures
To reduce the risk of electric shock, fire, explosion, serious injury or death:
• Disconnect electric power to the dryer(s) before servicing.
• Close gas shut-off valve to gas dryer(s) before servicing.
• Never start the dryer(s) with any guards/panels removed.
• Whenever ground wires are removed during servicing, these ground wires must be
reconnected to ensure that the dryer is properly grounded.
W001R1
WARNING
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
p. Lay cabinet top flat and remove two cap
screws, washers, lockwashers and nuts holding
front of timer case to cabinet top. Refer to
Figure 9.
q. Remove screw holding rear of case to cabinet
top and remove case. Refer to Figure 9.
31. CABINET TOP (Metered Models)
a. Remove two control panel attaching screws and
lay panel face down on protective padding on
cabinet top. Refer to Figure 8.
b. Disconnect all wires to components and
remove ground clip and screw holding ground
wire to cabinet top and control panel. Refer to
Figure 4.
NOTE: Refer to wiring diagram when reconnecting
wires.
c. Insert key in service door lock on top of meter
case and unlock door.
d. Lift rear of service door approximately 45° off
meter case to disengage notched tabs with
internal rib at top of meter case.
NOTE: When reinstalling service door and
accumulator, front end of door must be inserted at
a 45° angle in order to engage notched tabs with
internal rib at top of meter case.
e. Remove right mounting screw and slide
accumulator bracket back. Once left mounting
screw is over the keyhole opening, pull
accumulator and bracket up and out of meter
case. Refer to Figure 10.
NOTE: When reinstalling accumulator bracket,
push it completely forward before replacing the
right mounting screw.
f. Disconnect wires from accumulator. Refer to
Figure 10.
NOTE: Refer to wiring diagram when reconnecting
wires.
g. Remove hex head ground screw holding green
ground wire to accumulator mounting bracket.
Refer to Figure 10.
h. Remove two cap screws (inside meter case)
holding meter case to cabinet top. Refer to
Figure 10.
i. Remove nut, lockwasher and screw holding
meter case to right end of control hood. Refer to
Figure 12.
j. Remove two screws holding control hood to
cabinet top and lift hood off rear tabs. Refer to
Figure 8.
k. While supporting the access panel, remove two
screws from bottom edge of access panel. Refer
to Figure 7.
l. Gently lower the access panel to disengage
locators from bottom edge of front panel. Refer
to Figure 37.
m. Remove two screws holding bottom tabs on
front panel to dryer cabinet. Refer to Figure 37.
Swing bottom of front panel away from dryer to
disengage hold-down clips and locators from
cabinet top.
n. Disconnect wires from door switch. Refer to
Figure 27.
NOTE: Refer to wiring diagram when rewiring
switch.
NOTE: Accumulator and hardware must be
removed prior to raising cabinet top to a vertical
position. Refer to Figure 10.
o. Remove two cabinet top hold-down screws.
Refer to Figure 26.
p. Lift cabinet top to a vertical position by hinging
it on the rear hold-down brackets. Refer to
Figure 29.
NOTE: While servicing, cabinet top may be raised
and hinged on the rear hold-down brackets or
supported against wall behind dryer.
q. Carefully withdraw wire harness through hole
in cabinet top and lift the top off the rear hold-
down brackets with meter case attached. Refer
to Figure 29.
r. Lay cabinet top flat, remove carriage bolts,
washers, bracket, gasket, and nuts holding
meter case to cabinet top and remove the meter
case.
