27. TIMER CASE (Nonmetered Models)
a. Remove two control panel attaching screws and
lay panel face down on protective padding on
cabinet top. Refer to Figure 8.
b. Disconnect all wires from components and
remove ground clip and screw holding ground
wire to cabinet top and control panel. Refer to
Figure 4.
NOTE: Refer to wiring diagram when reconnecting
wires.
c. Remove four screws holding timer and plate to
timer case. Refer to Figure 9.
d. Pull timer and plate out of timer case as far as
wires will permit. Refer to Figure 9.
e. Remove ground wire from ground terminal on
timer. Refer to Figure 4.
f. Disconnect wires from timer.
NOTE: Refer to wiring diagram when rewiring
timer.
g. Remove cap screw, lockwashers and nut
holding timer case to control hood. Refer to
Figure 9.
h. While supporting the access panel, remove two
screws from bottom edge of access panel. Refer
to Figure 7.
i. Gently lower the access panel to disengage
locators from bottom edge of front panel. Refer
to Figure 37.
j. Remove two screws holding bottom tabs on
front panel to dryer cabinet. Refer to Figure 36.
Swing front panel away from dryer to
disengage hold-down clips and locators from
cabinet top.
k. Disconnect wires from door switch. Refer to
Figure 27.
NOTE: Refer to wiring diagram when rewiring
switch.
l. Remove two cabinet top hold-down screws.
Refer to Figure 28.
m. Lift cabinet top to a vertical position by hinging
it on the rear hold-down brackets. Refer to
Figure 29.
NOTE: While servicing, cabinet top may be raised
and hinged on the rear hold-down brackets or
supported against wall behind dryer.
n. Carefully withdraw wire harness through hole
in cabinet top and lift the entire cabinet top
assembly off the rear hold-down brackets.
Refer to Figure 29.
o. Lay the cabinet top assembly flat and remove
two carriage bolts and nuts holding front of
timer case to cabinet top. Refer to Figure 9.
p. Remove screw holding rear of case to cabinet
top and remove case. Refer to Figure 9.
