Section 5 Service Procedures
To reduce the risk of electric shock, fire, explosion, serious injury or death:
• Disconnect electric power to the dryer(s) before servicing.
• Close gas shut-off valve to gas dryer(s) before servicing.
• Never start the dryer(s) with any guards/panels removed.
• Whenever ground wires are removed during servicing, these ground wires must be
reconnected to ensure that the dryer is properly grounded.
W001R1
WARNING
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
(11) Reinstall multiplier and reconnect wires.
Refer to Figure 16.
(12) Close and lock service door.
Figure 23
Figure 24
W416SE1B
REAR OF
COIN DROP
COIN
DRAWER
HOUSING
COIN DROP
FRONT
FACE PLATE
W417SE1B
COIN DROP
FRONT
FACE PLATE
FRONT PLATE
OF METER CASE
Figure 25
25
¢
D391PE3C
25
¢
SCREW
SCREW
SCREW
LOCKNUT
LOCKNUT
SHOULDER
SCREW
BRACKET
METER
CASE
RETAINER
NUT
SERVICE
DOOR
