SPECIFICATIONS
Rear Panel I/O & switch :

MIDI In

MIDI Out with Phantom Power

MIDI Thru

Foot Controller 1 In (FC 1 In)

Foot Controller 2 In (FC 2 In

Patch Bay Switch 1 Out (PBS 1 Out)

Patch Bay Switch 2 Out (PBS 2 Out)

Patch Bay Switch 3 Out (PBS 3 Out)

Patch Bay Switch 4 Out (PBS 4 Out)

DC In

16 Switches, 3 Led
Display :

LCD 16 x 1
Mode :

Free

Patch

Set
Memory structure : (1 global, 10 sets, 100 patches)

Global parameter:
1. Power On 10 characters name
2. Power On Set and Patch Number
3. RX Basic Midi Channel for Set and Patch recall Program Changes
4. Foot Controller 1 min/max calibrate
5. Foot Controller 2 min/max calibrate
6. Continue switch assign

10 Sets
each containing:
1. 10 characters name
2. Song select to be sent (0~127/Off)
3. "A" part Midi Channel (1~16)
4. "B" part Midi Channel (1~16)
5. 10 Patches to be recalled

100 Patches
10 for each Set containing 2 parts (A,B) midi data:
1.
FC 1 assign to CC (0~120 on channel A/B,AB, Off with min and max value)
2.
FC 2 assign to CC (0~120 on channel A/B AB, Off with min and max value)
3.
FC1/2 link (On/Off)
4.
PBS 1-2-3-4 closed or opened (On/Off)
5.
"A"- CC 00 (0~127/Off)
6.
"A"- CC 32 (0~127/Off)
7.
"A"- PC (1~128/Off)
8.
"A"- xCC (0~120 at value 0~127/Off)
9.
"A"- yCC (0~120 at value 0~127/Off)
10.
"B"- CC 00 (0~127/Off)
11.
"B"- CC 32 (0~127/Off)
12.
"B"- PC (1~128/Off)
13.
"B"- xCC (0~120 at value 0~127/Off)
14.
"B"- yCC (0~120 at value 0~127/Off
