Fig. 2: Application examples for pH or Redox for two-way control
I.
First pump delta
®
with control module delta
®
II.
Second pump, e.g. Beta
®
1. Measurement water inflow (30 - 60 l/h)
2. Flow gauge (Part of the DGMA)
3. pH sensor (e.g. PHEP 112SE) or Redox sensor
(e.g. RHEP-Pt-SE)
4. pH measuring transducer (pHV1 / 809126) or
Redox measuring transducer (RHV1 / 809127)
5. Universal control wire (e.g. 1001300)
6. External wire (2-pin / e.g. 707702)
7. Metering tank with two-stage lance
8.
Relay cable (part of the delta
®
solenoid
metering pump)
9. Connecting box 1
10. External wire (2-pin / e.g. 707702)
11. Relay cable (3-pin, part of the external pump)
12. Connecting box 2
13. Diaphragm rupture cable
14. Suction lance
15. Collective alarm
