7
Measured variables for the control module delta
®
WARNING!
Danger of incorrect metering
This can result in hazardous incorrect metering
During initial commissioning, the measured variable
and the measuring range of the sensor must be set
prior to calibration.
When working on or with sensors, also observe the
respective technical documentation of the sensors.
Measurement range of the sensors
You must adapt the measuring range of the controller
to the measuring range of the chlorine sensor used.
Measured variable Preset measuring range (default)
Chlorine 10 ppm
The measuring range can be selected infinitely from 0.5 ... 20 ppm.
pH Measured variable Typical measuring range
Measuring range 0 ... 20 mA
Display range At least pH -1.45 … 15,45
Reference temperature + 25 °C
Resolution 0.01 pH
Redox measured variable Typical measuring range
Measuring range - 1,000 mV ... + 1,000 mV
Resolution 1 mV
Measured variables for the control module delta®
36
