6.12 Setting the "Two-pump mode"
The control module delta
®
can also be operated in two-pump
mode. Different parameters have to be entered for both pumps for
this purpose.
Clear
Main
proControl
Set
Controller
Set
Sensor calibr.
Concentration
Check out time
Controller
Reg. work set
2nd pump
2. Pump
Activate
no
Activate
yes
Strokes/min: [120]
2. Pump
Activate
Volumes : 25.0 l/h
2. Pump
Activate
Strokes/min: 120
Volumes : [25.0 l/h]
no
Activate
yes
A0324
Operation
Aux.
Hardware calib.
Strokes/min: 120
Volumes : 25.0 l/h
Fig. 18: Setting the "Two-pump mode"
The control module delta
®
now controls the second pump indirectly
via the relay output of the delta
®
solenoid metering pump.
Settings Comment
Activating
The controller is only active when the control relay in the delta
®
solenoid metering pump
has been activated.
Strokes / min. Stroke rate of the pump in strokes / minute. maximum 180 / min.
Volume Volumes in litre / hour
Operating Schematics / Display Symbols
