ProMinent delta - Calibrating the Sensor for pH

7.2 Calibrating the sensor for pH
Code
Main
Operation
Set
Controller
Set
Sensor calibr.
Concentration
Sensor calibr.
Sensor Calibr.
Calibration pH
Actual values
Calibration pH
Probe in buffer 1
Calibration pH
Adjust running:
4.00 pH
Calibration pH
Buffer 1: 4.00 pH
Temp: 25.0 °C
Calibration pH
Probe in buffer 2
Calibration pH
Adjust running
7.00 pH
Calibration pH
Buffer 2: 12.00 pH
Temp: 25.0 °C
Calibration pH
continue with P
Calibration pH
Actual values
Calibration pH
Z. point [11.85] mA
Slope at 25 °C
0.92 mA/pH
A0322
proControl
Aux.
continue with P
continue with P
continue with P
Actual values
Z. point [11.85] mA
Slope at 25 °C
0.92 mA/pH
Fig. 21: Calibrating the sensor for pH
