T
N
T
V
Controllers
0 0 P controller
>0 0 PI controller
0 >0 PD controller
>0 >0 PID controller
Sensor Parameter Comment
Chlorine Set point 0.01 ppm to the upper limit of the measuring range. In increments of 0.01
ppm. Start value: 50 % of the measuring range
X
p
0 to measuring range in increments of 0.01 ppm. Start value: 10 % of the
measuring range
T
N
0 s to 9999 s in increments of 1s. Start value 0 s.
T
V
0 s to 9999 s in increments of 1s. Start value 0 s.
pH Set point pH 0,01 pH to 14 pH in increments of 0.01 pH. Start value 50 % of meas‐
uring range
X
p
0 pH to measuring range in increments of 0.01 pH. Start value: 10 % of the
measuring range
T
N
0 s to 9999 s in increments of 1s. Start value 0 s.
T
V
0 s to 9999 s in increments of 1s. Start value 0 s.
Redox Set point 0 mV to 1,000 mV in increments of 1 mV. Start value: 50 % of the meas‐
uring range
X
p
0 mV to 1,000 mV in increments of 1 mV. Start value: 10 % of the meas‐
uring range
T
N
0 s to 9999 s in increments of 1s. Start value 0 s.
T
V
0 s to 9999 s in increments of 1s. Start value 0 s.
6.11
Factory settings of the control module delta
®
The factory settings that are loaded always refer to the current
sensor used (pH, Redox or chlorine).
If the request is acknowledged with
„yes“
, then the default values
for the characteristic curve data, measurement range, set value
and control parameters can be loaded.
Default values for the characteristic curve data
As the parameters for the characteristic curve are
default values, the sensors must be calibrated.
Operating Schematics / Display Symbols
