LED status control of the control module delta
®
The LED status control signalises the current operating status of
the control module delta
®
. There are different LED status displays:
The device LED and the connection LED. The LED status displays
do not have a flash mode.
Device LED
LED Status
Green Operating indicator
Red Fault display
n Internal hardware error
n Sensor error
Orange Warning display
n Configuration error
Connecting LED
LED Status
- Passive controller operation, otherwise okay
Green Active controller operation
Red No connection establishment to the pump
Troubleshooting
45

ProMinent delta Specifications

General

Stroke rate	max. 180 strokes/min
Type	Diaphragm metering pump
Materials	PVDF, PTFE, stainless steel
Protection class	IP 65
Diaphragm material	PTFE
Drive	Solenoid
Power supply	230 V, 50/60 Hz
