ProMinent gamma/ X User Manual

Read the following supplementary information in its entirety! Should you
already know this information, you will benefit more from referring to the
operating instructions.
The following are highlighted separately in the document:
n Enumerated lists
Instructions
ð
Outcome of the instructions
Ä ‘State the identity code and serial number’ on page 2 : Links to points in
this chapter
- refer to ... : References to points in this document or another document
[Keys]
‘Menu level 1
è Menu level 2 è Menu level ...’ : Menu paths
‘Software interface text’
Information
This provides important information relating to the correct
operation of the unit or is intended to make your work easier.
Safety Information
Safety information is identified by pictograms - see "Safety Chapter".
Please state the identity code and serial number, which you can find on
the nameplate or in the menu under
‘Setting / Menu è Information’ when
you contact us or order spare parts. This enables the unit type and mate‐
rial versions to be clearly identified.
Supplementary information
Fig. 1: Please read!
State the identity code and serial number
Supplemental instructions
2

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
