Figure 1. SmartStor NS2300N Front View
Figure 2. SmartStor NS2300N Rear View
Disk Drive
Drive Carrier
Drive Activity
LED
Power Button
Ethernet
Activity LED
Drive Status
LED
Note: This SmartStor is shown without the front door.
System Status LED
Power Connection
USB Connection
RJ45 Network Connection
Cooling Fan
