MVI69E-MBTCP ♦ CompactLogix Platform Diagnostics and Troubleshooting
Modbus TCP/IP Enhanced Communication Module User Manual
ProSoft Technology, Inc. Page 105 of 150
June 28, 2017
6.5.4 MBTCP Client-Specific Errors
Failed to connect to server specified in command
MBTCP command response timeout
TCP/IP connection ended before session finished
Note: If an error code is reported that is not listed above, check with the documentation of the end
device. Device-specific error codes can be produced by the end device.
6.6 Connecting to the MVI69E-MBTCP Webpage
The module’s internal web server provides access to module version and status
information, as well as the ability to set the date and time, reboot the module, and
download firmware upgrade to the module. Enter the assigned IP address of the
module into a web browser or use the following steps in PCB.
1 In the Diagnostics window in ProSoft Configuration Builder, click the SET UP
CONNECTION button.
2 In the Connection Setup dialog box, click BROWSE DEVICE(S) to start the
ProSoft Discovery Service.
