ProSoft Technology MVI69E-MBTCP User Manual

MVI69E-MBTCP ♦ CompactLogix Platform Using Controller Tags
Modbus TCP/IP Enhanced Communication Module User Manual
ProSoft Technology, Inc. Page 79 of 150
June 28, 2017
5.3 MBTCP Controller Tag Overview
You use controller tags to:
 View the read and write being transferred between the module and the
processor.
 View status data for the module.
 Set up and trigger special functions.
 Initiate module restarts (Warm Boot or Cold Boot).
Tag Name
Description
MBTCP.CONFIG
Configuration information
MBTCP.DATA
MBTCP input and output data transferred between the processor
and the module
MBTCP.CONTROL
Governs the data movement between the PLC rack and the
module
MBTCP.STATUS
Status information
MBTCP.UTIL
Generic tags used for internal ladder processing (DO NOT
MODIFY)
The following sections describe each of these controller tag structures in more
detail.
5.3.1 MBTCP.CONFIG
When ProSoft Configuration Builder (PCB) downloads the configuration file from
the PC to the processor, the processor stores the configuration file data in the
MBTCP.CONFIG.FileData array. Its CRC is also included in this array.
You cannot edit this array directly. You must use PCB to edit the module
configuration since PCB calculates a unique CRC to protect data integrity. Any
change to the configuration parameters directly in this array do not match the
calculated CRC.
Tag Name
Description
MBTCP.CONFIG.FileData
This parameter contains the MBTCP configuration data after it
has been downloaded from PCB. It is displayed in ASCII format.
Note: MBTCP configuration changes cannot be made directly in
this array; the configuration must be downloaded with PCB.
MBTCP.CONFIG.FileSize
Configuration file size (MBTCP.CONFIG.FileData array) in bytes.
MBTCP.CONFIG.FileCRC32
CRC checksum of the configuration file stored in the array.
MBTCP.CONFIG.FileStatus
Configuration file status. 0 = No file present, 1 = File present
