Loading...How to fix Link OFF on ProSoft Technology Control Unit?
If the 'Link' indicator is OFF, it means that the Control Unit does not detect a physical network connection. To solve this, check the wiring and cables to ensure they are properly connected.
What to do if the OK LED remains RED on ProSoft Technology Control Unit?
If the OK LED remains RED, it indicates that the program has halted or a critical error has occurred. To resolve this: * Connect to the Configuration/Debug port to see if the module is running. * Turn off power to the rack, remove the card from the rack and re-insert it, and then restore power to the rack.
Why is the BP ACT LED OFF or blinking slowly on my ProSoft Technology Control Unit?
If the BP ACT LED remains OFF or blinks slowly, this indicates that backplane transfer operations are failing. To establish backplane communications, verify the following items: 1. The processor is in RUN or REM RUN mode. 2. The backplane driver is loaded in the module. 3. The module is configured for read and write data block transfer. 4. The ladder logic handles all read and write block situations. 5. The module is properly configured in the processor I/O configuration and ladder logic.
What does it mean if BP ACT and OK LEDs blink at one-second intervals on ProSoft Technology Control Unit?
If the BP ACT and OK LEDs blink at a rate of every one-second, it indicates a serious problem with the module.
What does CLT Red mean on ProSoft Technology Control Unit?
If the CLT indicator is Red, it signifies that an exception response was received from the server, possibly due to a bad address or command.
What does SRV Red mean on ProSoft Technology Control Unit?
If the SRV indicator is Red, it means that an exception message was received from the client.
What does CFG Red mean on ProSoft Technology Control Unit?
If the CFG indicator is Red, it indicates an error in the configuration of the Control Unit.
What does BP Red mean on ProSoft Technology Control Unit?
If the BP indicator is Red, it signifies that the processor is not in RUN mode.
What does OK Red mean on ProSoft Technology Control Unit?
If the OK indicator is Red, it means that the application is not running.
General| Vendor | ProSoft Technology |
|---|---|
| Product Type | Control Unit |
| Protocol | Modbus TCP/IP |
| Ports | 1 Ethernet port |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -40 to 85°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Compatibility | Compatible with Rockwell Automation CompactLogix and MicroLogix Controllers |
| Power Supply | 24 VDC nominal |
