ProSoft Technology MVI69E-MBTCP User Manual

Using Controller Tags MVI69E-MBTCP ♦ CompactLogix Platform
User Manual Modbus TCP/IP Enhanced Communication Module
Page 86 of 150 ProSoft Technology, Inc.
June 28, 2017
MBTCP.CONTROL.GetEventDataStatus
This tag triggers the request of the event status.
Tag Name
Range
Description
MBTCP.CONTROL.
GetEventDataStatus
0 or 1
Triggers event status read
0 = Disable, 1 = Enable
MBTCP.CONTROL. ColdBoot
This tag triggers the processor to Coldboot the module (full reboot).
Tag Name
Range
Description
MBTCP.CONTROL.ColdBoot
0 or 1
Triggers a cold boot of the module
0 = Disable, 1 = Enable
MBTCP.CONTROL.WarmBoot
This tag triggers the processor to Warmboot the module (driver reboot).
Tag Name
Range
Description
MBTCP.CONTROL.WarmBoot
0 or 1
Triggers a warm boot the module
0 = Disable, 1 = Enable
5.3.4 MBTCP.STATUS
This array contains the status information of the module.
MBTCP.STATUS.Block
This array contains block status.
Tag Name
Description
MBTCP.STATUS.Block.Read
Total number of read blocks transferred from the module to the
processor
MBTCP.STATUS.Block.Write
Total number of write blocks transferred from the processor to
the module
MBTCP.STATUS.Block.Parse
Total number of blocks successfully parsed that were received
from the processor
MBTCP.STATUS.Block.Event
Total number of event command blocks received from the
processor
MBTCP.STATUS.Block.Cmd
Total number of command blocks received from the processor
MBTCP.STATUS.Block.Err
Total number of block transfer errors recognized by the module
