3.2.5 Ethernet 1
This section defines the permanent IP address, Subnet Mask, and Gateway of
the module.
In the ProSoft Configuration Builder tree view, double-click the ETHERNET 1 icon.
Parameter
Description
IP Address
Unique IP address assigned to the module
Netmask
Subnet mask of module
Gateway
Gateway (if used)
