ProSoft Technology MVI69E-MBTCP - Warm-Boot Control Block (9998); Cold-Boot Control Block (9999)

Reference MVI69E-MBTCP ♦ CompactLogix Platform
User Manual Modbus TCP/IP Enhanced Communication Module
Page 144 of 150 ProSoft Technology, Inc.
June 28, 2017
Block 9997: Response from Module to Processor
Offset
Description
0
Block ID 9997
1
Write Block ID
2-n
Spare
7.4.21 Warm-boot Control Block (9998)
If the CompactLogix sends a block number 9998, the module performs a warm-
boot operation. The module reconfigures the communication ports and reset the
error and status counters.
Block 9998: Request from Processor to Module
Offset
Description
0
Block ID 9998
1 to (n-1)
Spare
Where n = 60, 120, or 240 depending on the Block Transfer Size parameter.
7.4.22 Cold-boot Control Block (9999)
If the CompactLogix processor sends a block number 9999, the firmware
performs a cold-boot operation. The firmware reloads the configuration file from
the processor to the module and resets all MBTCP memory, error and status
data.
Block 9999: Request from Processor to Module
Offset
Description
0
Block ID 9999
1 to (n-1)
Spare
Where n = 60, 120, or 240 depending on the Block Transfer Size parameter.
