ProSoft Technology MVI69E-MBTCP - Start Here

MVI69E-MBTCP ♦ CompactLogix Platform Start Here
Modbus TCP/IP Enhanced Communication Module User Manual
ProSoft Technology, Inc. Page 9 of 150
June 28, 2017
1 Start Here
In This Chapter
 System Requirements ........................................................................... 10
 Deployment Checklist ............................................................................ 10
 Setting Jumpers .................................................................................... 11
 Installing the Module in the Rack ........................................................... 12
 Package Contents ................................................................................. 15
To get the most benefit from this User Manual, you should have the following
skills:
 Rockwell Automation
®
RSLogix™ software: launch the program, configure
ladder logic, and transfer the ladder logic to the processor
 Microsoft Windows: install and launch programs, execute menu commands,
navigate dialog boxes, and enter data
 Hardware installation and wiring: install the module, and safely connect
Modbus and CompactLogix devices to a power source and to the MVI69E-
MBTCP module’s Ethernet port
