ProSoft Technology MVI69E-MBTCP User Manual

MVI69E-MBTCP ♦ CompactLogix Platform Reference
Modbus TCP/IP Enhanced Communication Module User Manual
ProSoft Technology, Inc. Page 143 of 150
June 28, 2017
7.4.19 Pass Module Time to Processor Block (9973)
This block uses the time information of the module to set the processor time.
Block 9973: Request from Processor to Module
Offset
Description
0
Block ID 9973
1-n
Spare
Where n = 60, 120, or 240 depending on the Block Transfer Size parameter.
Block 9973: Response from Module to Processor
Offset
Description
0
Block ID 9973
1
Write Block ID
2
Year (0-9999)
3
Month (1-12)
4
Day (1-31)
5
Hour (0-23)
6
Minutes (0-59)
7
Seconds (0-59)
8
Milliseconds
9 to (n-1)
Spare
7.4.20 Reset Status Block (9997)
This block resets the module, port 1, and/or port 2 status.
Block 9997: Request from Processor to Module
Offset
Description
0
Block ID 9997
1
Reset Module status:
0=no, else yes
2
Reset Port 1 status:
0=no, else yes
3
Reset Port 2 status:
0=no, else yes
4 to (n-1)
Spare
Where n = 60, 120, or 240 depending on the Block Transfer Size parameter.
