MVI69E-MBTCP ♦ CompactLogix Platform Using Controller Tags
Modbus TCP/IP Enhanced Communication Module User Manual
ProSoft Technology, Inc. Page 87 of 150
June 28, 2017
MBTCP.STATUS.ClientStatus
This array contains the status of a specific MBTCP client (0 to 19).
MBTCP.STATUS.ClientStatus.
Request
Initiates request for Client Status block from module when set to 1
MBTCP.STATUS.ClientStatus.
ClientID
Specifies Client (0 to 19) to request status data from
MBTCP.STATUS.ClientStatus.
CommandRequests
Total number of requests made from this port to server devices on
the network
MBTCP.STATUS.ClientStatus.
CommandResponses
Total number of server response messages received on the port
MBTCP.STATUS.ClientStatus.
CommandErrors
Total number of command errors processed on the port. These
errors could be due to a bad response or command
MBTCP.STATUS.ClientStatus.
Requests
Total number of messages sent out of the port
MBTCP.STATUS.ClientStatus.
Responses
Total number of messages received on the port
MBTCP.STATUS.ClientStatus.
ErrorsSent
Total number of message errors sent out of the port
MBTCP.STATUS.ClientStatus.
ErrorsReceived
Total number of message errors received on the port
MBTCP.STATUS.ClientStatus.
ConfigErrorWord
Bitmap indicating general module configuration errors
MBTCP.STATUS.ClientStatus.
CurrentError
Most recent error code recorded for the client
MBTCP.STATUS.ClientStatus.
LastError
Previous most recent error code recorded for the client
MBTCP.STATUS.ClientStatus.
CmdErrors[x]
Command error code for each command (0-15) on the specified
client's command list
MBTCP.STATUS.EventSeqStatus
This array contains the status of the event command queue.
MBTCP.STATUS.EventSeqStatus.
ClientID
Specifies Client (0 to19) to request event status data from
MBTCP.STATUS.EventSeqStatus.
MessageCount
Number of event sequence messages in block (0 to 15)
MBTCP.STATUS.EventSeqStatus.
SeqNum_RetErrCode[x]
Sequence number returned error code
