ProSoft Technology MVI69E-MBTCP User Manual

Using Controller Tags MVI69E-MBTCP ♦ CompactLogix Platform
User Manual Modbus TCP/IP Enhanced Communication Module
Page 88 of 150 ProSoft Technology, Inc.
June 28, 2017
MBTCP.STATUS.EventSeqCounts
This array indicates the number of commands waiting in the command queue.
Tag Name
Description
MBTCP.STATUS.EventSeqCounts.
ClientCmdCount_EventSeqMessage
Event command quantity waiting in queue. There are two
bytes of status data per client. See below for details.
Byte 1: Number of Event sequence commands for which status has not yet been
retrieved (up to 15). This corresponds to the
MNETC.STATUS.EventSeqCmdPending.Client[x]_QueueCount controller tag.
Byte 2: Total number of commands waiting in the command queue. This includes
Event Commands, Event Commands with Sequence Numbers, and Command
Control messages. This corresponds to the
MBTCP.STATUS.EventSeqStatus.MessageCount controller tag.
MBTCP.STATUS.GeneralStatus
This array contains the general status of the module including firmware revision
and general communication status.
Tag Name
Description
MBTCP.STATUS.GeneralStatus.
ExpectedWriteBlock
Contains the next write block ID number
MBTCP.STATUS.GeneralStatus.
ProgramScanCount
Program cycle counter – increments each time a complete
program cycle occurs in the module
MBTCP.STATUS.GeneralStatus.
ProductCode
Product code
MBTCP.STATUS.GeneralStatus.
ProductVersion
Firmware revision level number
MBTCP.STATUS.GeneralStatus.
OperatingSystem
Operating level number
MBTCP.STATUS.GeneralStatus.
RunNumber
Run number
MBTCP.STATUS.GeneralStatus.
ReadBlockCount
Total number of read blocks transferred from the module to the
processor
MBTCP.STATUS.GeneralStatus.
WriteBlockCount
Total number of write blocks transferred from the processor to
the module
MBTCP.STATUS.GeneralStatus.
ParseBlockCount
Total number of blocks successfully parsed that were received
from the processor
MBTCP.STATUS.GeneralStatus.
CmdEventBlockCount
Total number of event command blocks received from the
processor
MBTCP.STATUS.GeneralStatus.
CmdBlockCount
Total number of command blocks received from the processor
MBTCP.STATUS.GeneralStatus.
ErrorBlockCount
Total number of block transfer errors recognized by the module
MBTCP.STATUS.GeneralStatus.
Client0CmdExecutionWord
Each bit in this word is used to enable/disable the commands for
client 0.
