ProSoft Technology MVI69E-MBTCP User Manual

MVI69E-MBTCP ♦ CompactLogix Platform Adding the Module to RSLogix
Modbus TCP/IP Enhanced Communication Module User Manual
ProSoft Technology, Inc. Page 35 of 150
June 28, 2017
5 Select the MVI69E-MBTCP module in the tree and repeat the above steps to
add a second (or more) module in the PCB project.
Note: You must give each MVI69E-MBTCP module a unique name. The default name on a
duplicate module appends a number to the end such as MVI69E-MBTCP_000, MVI69E-
MBTCP_001, etc.
6 You can rename the module by right clicking the module and selecting
Rename.
7 Configure the module parameters. See Module Configuration Parameters
(page 47), and then export the AOI .L5X file for the new module (right-click
the module and then choose EXPORT AOI FILE). See Creating and Exporting
the .L5X File (page 27).
