ProSoft Technology PLX3 Series User Manual

PLX3x Series PND Protocol
Ethernet and Serial Gateways User Manual
ProSoft Technology, Inc. Page 213 of 218
May 26, 2016
10.4 PND Diagnostics
10.4.1 PCB Diagnostics
The best way to troubleshoot the PND driver is to use ProSoft Configuration
Builder to access the diagnostic capabilities of the gateway through the Ethernet
debug port. For instructions on how to access Diagnostics, see Using
Diagnostics in ProSoft Configuration Builder (page 36).
10.4.2 PND Status Data in Upper Memory
The PND driver has an associated status data area located in the gateway’s
upper memory. The Data Map functionality of the gateway can be used to map
this data into the normal user data range of the gateway’s database. See Using
the CommonNet Data Map (page 25).
The following table lists the PND driver’s general status and error data that is
located in the gateway’s upper memory.
Note:
The status data starts at upper memory 6000 for the following gateways:
• PLX31-PND-MBS
• PLX31-PND-MBS4
The status data starts at upper memory 13000 for the following gateways:
• PLX31-EIP-PND
• PLX32-EIP-PND
• PLX31-MBTCP-PND
• PLX32-MBTCP-PND
Offset
Description
6000 / 13000
Total number of write messages to PLC
6001 / 13001
Total number of write message errors
6002 / 13002
Input Error message status. See below for error code descriptions.
6003 / 13003
Total number of read messages from PLC
6004 / 13004
Total number of read message errors
6005 / 13005
Output Error message status. See below for error code descriptions.
6006 / 13006
Connection Status
6007 / 13007
Driver Enabled? 1=Yes, 0=No
