Diagnostics and Troubleshooting PLX3x Series
User Manual Ethernet and Serial Gateways
Page 38 of 218 ProSoft Technology, Inc.
May 26, 2016
3.2.1 Diagnostics Menu
The Diagnostics menu is arranged as a tree structure, with the Main menu at the
top of the tree, and one or more submenus for each menu command.
The menu commands available will depend on the protocol combination of your
gateway.
Caution: Some of the commands available to you from this menu are designed for advanced
debugging and system testing only, and can cause the gateway to stop communicating with the
processor or with other devices, resulting in potential data loss or other communication failures.
Use these commands only if you fully understand their potential effects, or if you are specifically
directed to do so by ProSoft Technology Technical Support Engineers.
