PLX3x Series EIP Protocol
Ethernet and Serial Gateways User Manual
ProSoft Technology, Inc. Page 53 of 218
May 26, 2016
5.1.1 EtherNet/IP™ Client
In Client mode, the gateway controls the read/write data transfer between the
gateway and other EtherNet/IP devices.
Number of Clients Supported
Support for 100 commands per Client, each configurable for
command type, IP address, register to/from addressing and
word/bit count.
User-configurable polling of commands, including disabled,
continuous and on change of data (write only).
Other Configurable Parameters
Number of Commands (up to 100 per Client)
Min Command Delay
Response Timeout
Retry Count
Command Error Pointer
