EIP Protocol PLX3x Series
User Manual Ethernet and Serial Gateways
Page 58 of 218 ProSoft Technology, Inc.
May 26, 2016
5.2.3 EIP Class 3 Client/UClient [x] Connection
The PLX3x gateway supports two connected Clients and one unconnected Client
(most devices use connected Clients; be sure refer to the user manual of the
target device for verification).
The EIP Class 3 Client [x] Connections are used when the gateway is acting as a
Client/Master initiating message instructions to the server/slave devices. The
PLX3x EIP protocol supports three Connected Client Connections. Typical
applications include SCADA systems, and SLC communication.
The EIP Class 3 UClient Connection is used when the gateway is acting as a
Client/Master initiating message Instructions to the server/slave devices. The
PLX3x EIP protocol supports one Unconnected Client Connection. Unconnected
messaging is a type of Ethernet/IP explicit messaging that uses TCP/IP
implementation. Certain devices, such as the AB Power Monitor 3000 series B,
support unconnected messaging. Check your device documentation for further
information about its Ethernet/IP implementation.
Class 3 Client/UClient [x]
This section specifies the configuration for the EIP Client (Master) device on the
network port.
This parameter specifies the number of milliseconds to wait
between the initial issuances of a command. This parameter can
be used to delay all commands sent to servers to avoid
"flooding" commands on the network. This parameter does not
affect retries of a command as they will be issued when failure is
recognized.
This parameter specifies the amount of time in milliseconds that
a Client will wait before re-transmitting a command if no
response is received from the addressed server. The value to
use depends on the type of communication network used, and
the expected response time of the slowest device connected to
the network.
This parameter specifies the number of times a command will be
retried if it fails.
