ProSoft Technology PLX3 Series User Manual

EIP Protocol PLX3x Series
User Manual Ethernet and Serial Gateways
Page 92 of 218 ProSoft Technology, Inc.
May 26, 2016
Verify that the CIP radio-button is selected as the COMMUNICATION METHOD.
The PATH specifies the message route from the processor to the EIP gateway.
Path elements are separated by commas. In the example path shown, the first
element is "Enet", which is the user-defined name given to the 1756-ENET
gateway in the chassis (the slot number of the ENET gateway can be substituted
for the name), the second element, "2", represents the Ethernet port on the 1756-
ENET gateway, and the last element of the path, "192.168.0.75", is the IP
address of the gateway, the target for the message.
More complex paths are possible if routing to other networks using multiple 1756-
ENET gateways and racks. Refer to the Support Knowledgebase for more
information on Ethernet routing and path definitions.
5.4.4 EIP Command Entry Form
The following form can be used to design the application’s command list:
Gateway Information Data
Device Information Data
Column #
1
2
3
4
5
6
7
8
9
10
11
12
Function
Code
Enable
Code
Internal
Address
Poll
Interval
Time
Count
Swap
Code
IP
Address
Slot
Number
Function
Code
Function Parameters
IP Address = IP address of processor to reach
Slot Number = -1 for PLC5 & SLC, processor slot number of ControlLogix
