Diagnostics and Troubleshooting PLX3x Series
User Manual Ethernet and Serial Gateways
Page 36 of 218 ProSoft Technology, Inc.
May 26, 2016
3.2 Using Diagnostics in ProSoft Configuration Builder
ProSoft Configuration Builder (PCB) has many useful tools to help you with
diagnostics and troubleshooting. You can use PCB to connect to your gateway
and retrieve current status values, configuration data and other valuable
information.
Tip: You can have a ProSoft Configuration Builder Diagnostics window open for more than one
gateway at a time.
To connect to the gateway’s communication port
1 Start PCB, and then select the gateway. Click the right mouse button to open
a shortcut menu.
2 On the shortcut menu, choose DIAGNOSTICS.
