PLX3x Series EIP Protocol
Ethernet and Serial Gateways User Manual
ProSoft Technology, Inc. Page 55 of 218
May 26, 2016
MSG Instruction Type - PCCC
Database Address
File size 100
Database Address
File size 100
0
N10:0
0
N10:0
999
N19:99
999
N19:99
1000
N20:0
1000
N20:0
1999
N29:99
1999
N29:99
2000
N30:0
2000
N30:0
EtherNet/IP Explicit Messaging Server Command Support
The following commands are supported in the PLX3x gateway.
Basic Command Set Functions
Command
Function
Definition
Supported in Server
0x00
N/A
Protected Write
X
0x01
N/A
Unprotected Read
X
0x02
N/A
Protected Bit Write
X
0x05
N/A
Unprotected Bit Write
X
0x08
N/A
Unprotected Write
X
PLC-5 Command Set Functions
Command
Function
Definition
Supported in Server
0x0F
0x00
Word Range Write (Binary Address)
X
0x0F
0x01
Word Range Read (Binary Address)
X
0x0F
Typed Range Read (Binary Address)
X
0x0F
Typed Range Write (Binary Address)
X
0x0F
0x26
Read-Modify-Write (Binary Address)
0x0F
0x00
Word Range Write (ASCII Address)
X
0x0F
0x01
Word Range Read (ASCII Address)
X
0x0F
0x26
Read-Modify-Write (ASCII Address)
SLC-500 Command Set Functions
Command
Function
Definition
Supported in Server
0x0F
0xA1
Protected Typed Logical Read With Two
Address Fields
X
0x0F
0xA2
Protected Typed Logical Read With Three
Address Fields
X
0x0F
0xA9
Protected Typed Logical Write With Two
Address Fields
X
0x0F
0xAA
Protected Typed Logical Write With Three
Address Fields
X
0x0F
0xAB
Protected Typed Logical Write With Mask (Three Address Fields)
