ProSoft Technology PLX3 Series User Manual

PLX3x Series EIP Protocol
Ethernet and Serial Gateways User Manual
ProSoft Technology, Inc. Page 63 of 218
May 26, 2016
Parameter
Value
Description
File Type
Binary
Counter
Timer
Control
Integer
Float
ASCII
String
Status
Specifies the file type to be associated with the
command.
File Number
-1
Specifies the SLC 500 file number to be associated with
the command. If a value of -1 is entered for the
parameter, the field will not be used in the command,
and the default file will be used.
Element
Number
Specifies the element in the file where the command
will start.
Sub Element
Specifies the sub-element to be used with the
command. Refer to the AB documentation for a list of
valid sub-element codes.
Comment
This field can be used to give a 32 character comment
to the command.
