ProSoft Technology PLX3 Series User Manual

PLX3x Series EIP Protocol
Ethernet and Serial Gateways User Manual
ProSoft Technology, Inc. Page 75 of 218
May 26, 2016
Code (Int)
Code (Hex)
Description
-4070
0xF01A
File is open; another node owns it
-4069
0xF01B
Another node is the program owner
-4068
0xF01C
Reserved
-4067
0xF01D
Reserved
-4066
0xF01E
Data table element protection violation
-4065
0xF01F
Temporary internal problem
Gateway Specific Error (not EIPCompliant)
Code (Int)
Code (Hex)
Description
-1
0xFFFF
CTS modem control line not set before transmit
-2
0xFFFE
Timeout while transmitting message
-10
0xFFF6
Timeout waiting for DLE-ACK after request
-11
0xFFF5
Timeout waiting for response after request
-12
0xFFF4
Reply data does not match requested byte count
-20
0xFFEC
DLE-NAK received after request
-21
0xFFEB
DLE-NAK sent after response
-200
0xFF38
DLE-NAK received after request
TCP/IP Interface Errors
Error (Int)
Error (Hex)
Description
-33
0xFFDF
Failed to connect to target
-34
0xFFDE
Failed to register session with target (timeout)
-35
0xFFDD
Failed forward open response timeout
-36
0xFFDC
PCCC/Tag command response timeout
-37
0xFFDB
No TCP/IP connection error
Common Response Errors
Error (Int)
Error (Hex)
Description
-40
0xFFD8
Invalid response length
-41
0xFFD7
CPF item count not correct
-42
0xFFD6
CPF address field error
-43
0xFFD5
CPF packet tag invalid
-44
0xFFD4
CPF bad command code
-45
0xFFD3
CPF status error reported
-46
0xFFD2
CPF incorrect connection ID value returned
-47
0xFFD1
Context field not matched
-48
0xFFD0
Incorrect session handle returned
-49
0xFFCF
CPF not correct message number
