10.8 Disabling and Enabling an Individual Device
1. Enter the engineer code supplied with the system to access the menus.
2. Scroll to the DISABLEMENT SETUP menu and press the ↵
↵↵
↵ key. The disablement screen is shown
(figure 10.3).
3. Using the ▼ key scroll to the DEVICE option and press the ↵
↵↵
↵ key. The device disablement screen is
shown (figure 10.4).
4. Press the▲ or ▼ keys to select the address.
5. Press the◄ or ► keys to toggle between disabling and enabling the address.
The current state is shown as ENABLED or DISABLED in the top right of the screen.
6. Press the Back key to return to the DISABLEMENT OPTIONS menu, or the Escape key to exit the
menus completely
Group disablements take precedence over device disablements. A device that is in a
disabled group cannot be individually enabled. The whole group must be enabled.
Figure 10.3 Disablement Options Screen
Figure 10.4 Device Disablement Screen
ADDRESS 345 ENABLED
ADDRESS TEXT XXXXXXX
DEVICE disablement
option
disABLEMENT SETUP
GROUP
DEVICE
BUZZER ENABLED
Indicates if address is
ENABLED or DISABLED
Programmed address text
Loop address
