Protec Digilite DL500 - Editing Device Location Text; Editing Group Text

N93-582-01 Issue 1 NH Page 28 of 42 © Protec Fire Detection plc 2015
10.10 Editing Device Location Text
The Edit Device Text menu allows the user to enter 20 characters of text for any loop device on the
Digilite® DL500.
1. Enter the user code supplied with the system and press the ↵
↵↵
↵ key to access the menus.
2. Using the ◄ and ► keys navigate to the EDIT DEVICE TEXT menu and press ↵
↵↵
↵.
3. Using the ◄ and ► keys navigate to the device address that you wish to edit the text on and
press the ↵
↵↵
↵ key to enter editing mode ( Figure 10.7 ).
4. Using the ◄ and ► keys navigate through the text characters then ( the character being edited
has a ^ positioned underneath it ), then using the ▲ and ▼ keys, edit the character as required.
5. Press the ↵
↵↵
↵ key to accept the changes and return to the main menu.
Figure 10.7 – Edit Device Text display
10.11 Editing Group Text
The Edit Group Text menu allows the user to enter 20 characters of text for each of the 28 groups
available on the Digilite® DL500.
1. Enter the user code supplied with the system and press the ↵
↵↵
↵ key to access the menus.
2. Using the ◄ and ► keys navigate to the EDIT GROUP TEXT menu and press ↵
↵↵
↵.
3. Using the ◄ and ► keys navigate to the group that you wish to edit the text on and press the ↵
↵↵
↵
key to enter editing mode ( Figure 10.8 ).
4. Using the ◄ and ► keys navigate through the text characters then ( the character being edited
has a ^ positioned underneath it ), then using the ▲ and ▼ keys, edit the character as required
5. Press the ↵
↵↵
↵ key to accept the changes and return to the main menu.
Figure 10.8 – Editing Group Text display
GROUP 16
GROUP TEXT FOR ZONE 16
^ . . . . . . . . . . . . . . . . . .
Address 001 LEDDRV
Device text addRESS 1
^ . . . . . . . . . . . . . . . . . .
